MX Series 3D Universal Edge Routers
Provides Ethernet switching capabilities without sacrificing carrier-class routing features. Offers high performance, high port-density routing and switching functionality for both service providers and enterprise networks. EANTC verification of bandwidth, subscribers, and services scale.
Test Report: EANTC Juniper Networks MX Series 3D with Junos Trio Chipset
FEATURED NEW PRODUCTSThe new MX5, MX10, and MX40 ethernet routers bring the outstanding performance of Juniper's 3D routing to mid-range applications. |
|
The MX Series 3D Universal Edge Routers is a portfolio of high-performance Ethernet routers which function as a Universal Edge platform capable of supporting all types of business, mobile, and residential services. Powerful switching and security features give the MX Series 3D Universal Edge Routers unmatched flexibility and reliability to support advanced services and applications.
MX Series ethernet routers separate control and forwarding functions to provide maximum scale and intelligent service delivery capabilities. MX Series 3D Universal Edge Routers are optimized for Ethernet services and address a wide range of deployments, architectures, port densities, and interfaces, for both service provider and enterprise environments.
The MX Series 3D Universal Edge Routers provide the 3D scale, maximum performance, availability, and service agility, that enterprises and service providers need to gain a competitive advantage in today’s Ethernet environment.
The MX Series 3D Universal Edge Routers based on the Junos Trio chipset delivers 3D scalability for bandwidth, subscribers and services:
- Bandwidth: Support the ever-increasing bandwidth demand with an industry leading capacity with of up to 2.6 Tbps in a 16 RU chassis.
- Subscriber: Scale to support the growing subscriber base for the service providers with up to 32k subscribers per packet forwarding engine.
- Services: Enhance delivery of intelligent services and applications with quality and performance that meets customer expectations.
|
MX5 3D Universal Edge Router
The MX5 3D Universal Edge Router delivers a cost-effective platform in a compact form factor. MX5 is a versatile platform for small scale environments with space and power constraints, for both enterprise and service provider networks that need full MX Series features and capabilities. The Ethernet services router supports one MIC slot and is software upgradable to MX10, MX40 or MX80. Learn more |
|
MX10 3D Universal Edge Router
The MX10 3D Universal Edge Router is a versatile platform for small scale environments with space and power constraints. Its compact form factor makes it a cost-effective platform for both enterprise and service provider networks needing full MX Series features and capabilities. The Ethernet services router supports two MIC slots and is software upgradable to MX40 or MX80. Learn more |
|
MX40 3D Universal Edge Router
The MX40 3D Universal Edge Router supports two MIC slots, two built in 10GE ports in a compact form factor that makes it powerful but cost-effective platform for small scale environments with space and power constraints in both enterprise and service provider networks that need full MX Series features and capabilities. The Ethernet services router supports two MIC slots and is software upgradable to an MX80. Learn more |
|
MX80 3D Universal Edge Router
The MX80 3D Universal Edge Router integrates carrier Ethernet capabilities and a modular port concentrator (MPC) design to create a cost-effective Ethernet service solution ideal for environments with severely limited space. Learn more |
|
MX240 3D Universal Edge Router
The MX240 3D Universal Edge Router delivers increased port density over traditional carrier Ethernet service platforms as well as performance of 200+ Gbps throughput, scalability, and reliability in a space-efficient package. Learn more |
|
MX480 3D Universal Edge Router
The MX480 3D Universal Edge Router provides a dense, highly redundant Ethernet platform primarily targeted for dense dedicated access aggregation and provider edge services in medium-size and large Points of Presence (POPs). Learn more |
|
MX960 3D Universal Edge Router
The MX960 3D Universal Edge Router is a high-density Layer 2 and Layer 3 Ethernet service platform for several service provider Ethernet edge scenarios. This enterprise Ethernet service provider router provides a range of Ethernet services, including VPLS services for multi-point connectivity. Learn more |
| Advantage | Features | Benefits |
|---|---|---|
| High Availability |
|
The MX Series provides the highest level of redundancy and resiliency. Critical services and customers stay connected, and service providers can maximize revenue and ensure customer satisfaction. |
| High Performance |
|
The MX Series meets the needs of critical applications at the edge, including voice, video, and data. |
| Service Flexibility | Simultaneous support for Layer 2 and Layer 3 Ethernet services: VPLS, RFC 2547bis IP/MPLS VPNs, Triple Play services | Providing enterprise and residential services increases service breadth and optimizes OpEx and CapEx. |
ACG Research—Juniper Networks Universal Edge: Scaling for the New Network
705 KB ]
MX Series 3D: Pushing New Boundaries with the Junos Trio Chipset — EANTC Independent Validation
“The capabilities enabled by the Junos Trio chipset showed very impressive results. We see Juniper pushing new boundaries concurrently for Ethernet density, services, and subscriber scale, as well as for power efficiency.”
Managing Director, EANTC
The independent performance verification conducted by the European Advanced Network Test Center (EANTC) was commissioned by Juniper Networks to confirm the breakthrough capabilities of the new Junos Trio-based MX80 3D Universal Edge Router and new 16x10GbE line cards.
The EANTC validation report [PDF 449 KB] demonstrates that network operators, service providers, and enterprises can transform quality of experience and business economics with Junos Trio-based products.
Tested to have three-dimensional (3D) bandwidth, subscribers, and services scale, the MX Series 3D Universal Edge Routers enable innovative services with premium user experience for a new breed of media-rich, high-performance applications.
EANTC "3D" Validation Highlights
Density, Throughput, Scale
- 1.440 Tbit/s measured in 1/6th of a rack (8.64 Tbit/s rack equivalent, extrapolated)
- 96 10GbE ports in 1/6th of a rack (528/rack equivalent, extrapolated)
- 240 Gbit/s unidirectional throughput per MX Series 3D slot
- 1+ billion packets per second for IPv4, IPv6, unicast and multicast
- 0% packet loss under all test conditions
Services Scale
- Virtual private LAN service (VPLS) and IP/MPLS VPN (L3VPN)
- 6,000 concurrent active VPLS service instances at scale
- 6,000 concurrent active L3VPN service instances at scale
- 2.4 million unique active VPN routes
- Media-rich and transactional services
- 60,000 multicast groups
- 3,300 replications per content stream
- 660,000 receivers per line card
Power Efficiency and Carbon Footprint
- 25.34 watts per 10GbE with fully loaded chassis at 100% load
- 2,433 watts per MX480 3D chassis at 100% load
- 3.38 watts per gigabit of throughput
Rich Application Support
- Functional validation of the MX80 and Junos Universal Edge services as applicable to telcos, cable companies, enterprises, ASPs, CDNs, and beyond.
Additional Information
- EANTC Report: MX Series 3D with Junos Trip Chipset [PDF 449 KB]
- Junos Trio: Programmable Silicon Optimized for the Universal Edge [PDF 338 KB]
The rigorous tests were conducted in September 2009 by EANTC, with support from Juniper using Ixia IxNetwork testing solutions.
