Step 2: Up and Running

View and Troubleshoot Data Center Events

After Apstra Edge is registered, Juniper Data Center Assurance starts receiving data center events and Apstra flow information from Apstra Edge. You can use the visualizations of the Apstra flow information to understand how the services and clients are utilizing the data center network.

Administrators can view the data center events and anomalies in real-time and resolve them proactively before they impact network traffic. You can view these events and anomalies in the Marvis Actions dashboard and on the App Aware and Impact Analysis pages. To troubleshoot events, you can access Apstra Data Center Director from DC Assurance.

For more information about viewing and troubleshooting data center events, see View Data Center Events in Marvis Actions, Access Apstra Data Center Director from Juniper Data Center Assurance, and Impact Analysis.

Access DC Assurance from Mist

If you manage your enterprise network using Mist and data center using Apstra Data Center Director, you can monitor data center events too from Mist by linking the organization in Mist with the organization in DC Assurance. Once the organization in Mist is linked to the organization in DC Assurance, you can view the total number of data center events on the in Data Center/Application on the Marvis Actions page in Mist. To view more detailed information about an event, you need to access DC Assurance by clicking the Data Center Actions event type under Data Center/Application.

You must be a user with Super User or a Network Admin role to perform this task.

To enable DC Assurance from Mist:

  1. Log into DC Assurance.
  2. From the Organization > Settings page, generate an API token.
  3. Log into Juniper Mist portal.
  4. Navigate to Organization > Settings page.
  5. Locate the Apstra Cloud Services Integration tile.

    Enter the following information:

    • Organization ID─Copy the organization ID from DC Assurance and paste it here.

    • API Token─Copy the API token generated in step 2 in DC Assurance and paste it here.

    • API Token Name─Enter the API token name that you defined in DC Assurance.

  6. Click Save.
    The organizations in Mist and DC Assurance are linked now. In a few minutes, you'll notice that Data Center/Application in Marvis Actions in Mist is active and displays the total number of data center events under the Data Center Actions event type.
  7. Click the Data Center Actions event type under Data Center/Application to launch DC Assurance.
    DC Assurance opens in a new browser window or tab in read-only mode. Log in to DC Assurance to access all features of the application.

Configure Organization Settings

A super user in DC Assurance can configure organization settings and perform the following tasks:

  • View organization name and organization ID and modify the organization name.

  • Enable or disable the password policy for the organization and modify the password policy when the password policy is enabled.

  • Modify the session timeout policy for the organization.

  • Add, modify, and delete identity providers.

  • Add, modify, and delete custom roles.

  • Configure webhooks for the organization.

  • Add Juniper account to link Juniper Networks devices to the organization.

  • Generate, edit, and delete API tokens for various roles in the organization.

For detailed information and the steps to configure organization settings, see Manage Organization Settings.

Add Users to Administrator Roles

To add users to an organization, you must be a user with the Super User privileges. You add a user by sending them an invite from DC Assurance. When you send an invite, you can assign a role to the user depending on the function they need to perform in the organization.

To add user to the organization:

  1. Click Organization > Administrators.
  2. On the Administrators page, click Invite Administrators.
  3. In the Administrators :New Invitation page, enter the user details such as e-mail address, first name and last name, and the role that the user should perform in the organization. For more information about roles in DC Assurance, see Predefined User Roles Overview.
    The first name and the last name can be up to 64 characters each.
  4. Click Invite.
    An e-mail invite is sent to the user and the Administrators page displays the status of the user as Invited.
  5. (Optional) Repeat the above steps to add more users to the organization.
