Dimensions without Modem Cap
- 130mm x 230mm x 40mm
Dimensions with Integrated Modem Cap
- CX-MC200LE-VZ: 185mm x 230mm x 40mm (without antennas)
Ethernet
- 1x10/100 Auto MDIX
PoE
- 802.3af (<4W typical with 1-Modem connected)
USB ports
- 3x USB2.0 (1 available if using CX-MC200LE-VZ)
ExpressCard ports
- 1xExpressCard/34 (none available if using CX-MC200LE-VZ)
Modem Types Supported*
- LTE/EV-DO, 4G LTE/HSPA and WiMAX
Modem Usage
- Up to 4 can be connected. One Modem used at a time. If using CX-MC200LE-VZ, only 1 additonal USB modem can be supported.
Modem Cap
- Can be used to conceal modems, if not using CX-MC200LE-VZ integrated modem cap.
Buttons
- Signal Strength Button
- Activation Button
- Reset Button (recessed)
Switches
- Mode Selector (pass-through 'or' Local Management)
- Power on/off
Power Plug
- 12VDC input (used if PoE not available)
Power Supply
- 30W, included
LEDs
- Power (HW)
- USB Modem Status (x3)
- ExpressCard Modem Status (x1)
- Modem Signal Strength (x4)
- LAN Activity (HW)
- Data
- Info LEDs: Fail-over, Low-Speed, PoE Power, Config Mode, Attention
- Activation
Modem Features
- CX-MC200LE-VZ
- Technology: LTE 3GPP Rel.8, EVDO RevA,A/0; CDMA 1x
- Network, Region: Verizon USA network, LTE/EV-DO
- Downlink rates: LTE 100Mbps, EVDO 3.1Mbps (theoritical)
- Uplink rates: LTE 50Mbps, EVDO 1.8Mbps (theoritical)
- Frequency band: LTE Band 13 (700MHz), Cellular/PCS (800MHz/1,900 MHz)
- Module: Seirra Wireless MC7750
499 KB ]
|
| Part Number | Description |
|---|---|
| CX111-3G-BRIDGE | Ethernet (PoE powered) Wireless WAN bridge supports 3G/HSPA/EVDO/WiMAX/LTE USB or ExpressCard Modems. Connects to SRX, J-Series and SSG platforms. Power supply and modemcover included. 3G/4G LTE modem NOT included. |
| CX111-MC200LE-VZ-BNDL | Bundle package includes CX111 Bridge and LTE/EV-DO business-grade modem for Verizon USA LTE/EV-DO connectivity. |
| CX-MC200LE-VZ | LTE/EV-DO business-grade modem for Verizon USA LTE/EV-DO connectivity. Requires CX111 Bridge (sold separately). |
