ScreenOS version tested
ScreenOS 6.2
ScreenOS 6.2
Firewall Perf (Large Packets)
1+ Gbps
1+ Gbps
Firewall Performance (IMIX)
1 Gbps
1 Gbps
Firewall Packets Per Second
600,000 PPS
600,000 PPS
3DES+SHA-1 VPN Perf
600 Mbps
600 Mbps
Concurrent VPN Tunnels
1,000
1,000
Max Concurrent Sessions
256,000
256,000
New Sessions/Second
15,000
15,000
Max Security Policies
4,000
4,000
Max Security Zones
60
60
Max Virtual Routers
16
16
Max Virtual LANs
150
150
Fixed I/O
4x10/100/1000
4x10/100/1000
Mini-Physical Interface Module (Mini-PIM) Expansion Slots
0
0
Physical Interface Module (PIM) Expansion Slots
2
2
Enhanced PIM (EPIM) Expansion Slots
4
4
802.11 a/b/g
No
No
Convertible to JUNOS
Yes
Yes
Physical Interface Module (PIM) Compatibility Matrix for J Series Routers and SSG Series Secure Services Gateways
Download
[
215 KB ]
ADSL/ADSL2/ADSL2+ Physical Interface Modules
Download
[ 934 KB ]
G.SHDSL Physical Interface Module
Download
[ 1.19 MB ]
Ethernet Universal Physical Interface Modules
Download
[ 1.73 MB ]
Dual-Port T1/E1 Physical Interface Module
Download
[ 1.15 MB ]
Dual-Port Synchronous Serial Physical Interface Module
Download
[ 887 KB ]
ISDN BRI S/T PIM
Download
[ 656 KB ]
Ethernet Enhanced Physical Interface Modules
Download
[ 484 KB ]
Juniper Networks Integrated Firewall/VPN Platforms
Download
[ 934 KB ]
| Part Number | Description |
|---|---|
| SSG550M | |
| SSG-550M-SH | SSG550M with 1 GB Memory, 0 PIM Cards, 1 AC Power Supply |
| SSG-550M-SH-N | SSG550M with 1 GB Memory, 0 PIM Cards, 1 AC Power Supply, NEBS Compliant |
| SSG-550M-SH-DC-N | SSG550M with 1 GB Memory, 0 PIM Cards, 1 DC Power Supply, NEBS Compliant |
| SSG-550M-SH-N-TAA | SSG550M System, 1GB DRAM, 1 AC Power Supply, NEBS and TAA Compliant |
| SSG-550M-SH-DC-N-TAA | SSG550M System, 1GB DRAM, 1 DC Power Supply, NEBS and TAA Compliant |
| Unified Threat Management/Content Security (High Memory Option Required) | |
| NS-K-AVS-SSG550 | Antivirus (includes anti-spyware, anti-phishing) |
| NS-DI-SSG550 | IPS (Deep Inspection) |
| NS-WF-SSG550 | Web filtering |
| NS-SPAM-SSG550 | Anti-spam |
| NS-RBO-CS-SSG550 | Remote Office Bundle (Includes AV, DI, WF) |
| NS-SMB-CS-SSG550 | Main Office Bundle (Includes AV, DI, WF, AS) |
