ScreenOS version tested
ScreenOS 6.2
ScreenOS 6.2
Firewall Perf (Large Packets)
650+ Mbps
650+ Mbps
Firewall Performance (IMIX)
600 Mbps
600 Mbps
Firewall Packets Per Second
300,000 PPS
300,000 PPS
3DES+SHA-1 VPN Perf
300 Mbps
300 Mbps
Concurrent VPN Tunnels
500
500
Max Concurrent Sessions
128,000
128,000
New Sessions/Second
10,000
10,000
Max Security Policies
4,000
4,000
Max Security Zones
60
60
Max Virtual Routers
11
11
Max Virtual LANs
125
125
Fixed I/O
4x10/100/1000
4x10/100/1000
Mini-Physical Interface Module (Mini-PIM) Expansion Slots
0
0
Physical Interface Module (PIM) Expansion Slots
4
4
Enhanced PIM (EPIM) Expansion Slots
2
2
802.11 a/b/g
No
No
Convertible to JUNOS
Yes
Yes
Physical Interface Module (PIM) Compatibility Matrix for J Series Routers and SSG Series Secure Services Gateways
Download
[
215 KB ]
ADSL/ADSL2/ADSL2+ Physical Interface Modules
Download
[ 934 KB ]
G.SHDSL Physical Interface Module
Download
[ 1.19 MB ]
Ethernet Universal Physical Interface Modules
Download
[ 1.73 MB ]
Dual-Port T1/E1 Physical Interface Module
Download
[ 1.15 MB ]
Dual-Port Synchronous Serial Physical Interface Module
Download
[ 887 KB ]
ISDN BRI S/T PIM
Download
[ 656 KB ]
Ethernet Enhanced Physical Interface Modules
Download
[ 484 KB ]
Juniper Networks Integrated Firewall/VPN Platforms
Download
[ 934 KB ]
| Part Number | Description |
|---|---|
| SSG520M | |
| SSG-520M-SH | SSG520M with 1 GB Memory, 0 PIM Cards, 1 AC Power Supply |
| SSG-520M-SH-N | SSG520M with 1 GB Memory, 0 PIM Cards, 1 AC Power Supply, NEBS Compliant |
| SSG-520M-SH-N-TAA | SSG520M System, 1GB DRAM, 1 AC Power Supply –NEBS and TAA Compliant |
| SSG-520M-SH-DC-N-TAA | SSG520M System, 1GB DRAM, 1 DC Power Supply – NEBS and TAA Compliant |
| SSG-520M-SH-DC-N | SSG520M with 1 GB Memory, 0 PIM Cards, 1 DC Power Supply, NEBS Compliant |
| SSG520M | |
| SSG-520M-SH | SSG520M with 1 GB memory, 0 PIM Cards, 1 AC power supply |
| SSG-520M-SH-N | SSG520M with 1 GB memory, 0 PIM Cards, 1 AC power supply, NEBS Compliant |
| SSG-520M-SH-N-TAA | SSG520M System, 1 GB DRAM, 1 AC power supply - NEBS and TAA Compliant |
| SSG-520M-SH-DC-N-TAA | SSG520M System, 1 GB DRAM, 1 DC power supply - NEBS and TAA Compliant |
| SSG-520M-SH-DC-N | SSG520M with 1 GB memory, 0 PIM Cards, 1 DC power supply, NEBS Compliant |
| SSG500 Line I/O Options | |
| JXE-1GE-TX-S | 1 Port Gigabit Ethernet 10/100/1000 Copper Enhanced PIM1 |
| JXE-1GE-SFP-S | 1 Port Fiber Gigabit Ethernet Enhanced PIM (SFP sold separately) |
| JXE-4FE-TX-S | 4 Port Fast Ethernet Enhanced PIM1 |
| JXU-1SFP-S | 1 Port SFP 100 Mbps or Gigabit Ethernet Universal PIM (SFP sold separately) |
| JX-SFP-1GE-LX | Small Form Factor Pluggable 1000Base-LX Gigabit Ethernet Optical Transceiver Module |
| JX-SFP-1GE-SX | Small Form Factor Pluggable 1000Base-SX Gigabit Ethernet Optical Transceiver Module |
| JX-2T1-RJ48-S | 2 Port T1 PIM with integrated CSU/DSU |
| JX-2E1-RJ48-S | 2 Port E1 PIM with integrated CSU/DSU |
| JX-2Serial-S | 2 Port Serial PIM |
| JX-1ADSL-A-S | 1 Port ADSL 2/2+ Annex A PIM |
| JX-1ADSL-B-S | 1 Port ADSL 2/2+ Annex B PIM |
| JX-2SHDSL-S | 1 Port G.SHDSL PIM |
| JX-1DS3-S | 1 Port DS3 PIM |
| JX-1E3-S | 1 Port E3 PIM |
| JXU-6GE-SFP-S | 6 Port SFP Gigabit Ethernet Universal PIM2 |
| JXU-8GE-TX-S | 8 Port Gigabit Ethernet 10/100/1000 Copper Universal PIM2 |
| JXU-16GE-TX-S | 16 Port Gigabit Ethernet 10/100/1000 Copper Universal PIM2 |
| Unified Threat Management/Content Security (High Memory Option Required) | |
| NS-K-AVS-SSG520 | Antivirus (includes anti-spyware, anti-phishing) |
| NS-DI-SSG520 | IPS (Deep Inspection) |
| NS-WF-SSG520 | Web filtering |
| NS-SPAM-SSG520 | Anti-spam |
| NS-RBO-CS-SSG520 | Remote Office Bundle (Includes AV, DI, WF) |
| NS-SMB-CS-SSG520 | Main Office Bundle (Includes AV, DI, WF, AS) |
