SSG Series

Secure Services Gateways

High-performance security platforms that stop internal and external attacks with models for deployments from small branch offices to large global networks.

How to Buy

Compare All SSG Series Products

Product Comparison

SSG5SSG20SSG140SSG320MSSG350MSSG520MSSG550M
ScreenOS version testedScreenOS 6.3ScreenOS 6.3ScreenOS 6.2ScreenOS 6.3ScreenOS 6.3ScreenOS 6.2ScreenOS 6.2
Firewall Perf (Large Packets)160 Mbps160 Mbps350+ Mbps450+ Mbps550+ Mbps650+ Mbps1+ Gbps
Firewall Performance (IMIX)90 Mbps90 Mbps300 Mbps400 Mbps500 Mbps600 Mbps1 Gbps
Firewall Packets Per Second30,000 PPS30,000 PPS100,000 PPS175,000 PPS225,000 PPS300,000 PPS600,000 PPS
3DES+SHA-1 VPN Perf40 Mbps40 Mbps100 Mbps175 Mbps225 Mbps300 Mbps600 Mbps
Concurrent VPN Tunnels25/40*25/40*5005005005001,000
Max Concurrent Sessions8,000/16,000*8,000/16,000*48,00064,000128,000128,000256,000
New Sessions/Second2,8002,8008,0008,00012,50010,00015,000
Max Security Policies2002001,0002,0002,0004,0004,000
Max Security Zones883040406060
Max Virtual Routers3/4*3/4*6881116
Max Virtual LANs10/50*10/50*100125125125150
Fixed I/O7x10/1005x10/1008x10/100, 2x10/100/10004x10/100/10004x10/100/10004x10/100/10004x10/100/1000
Mini-Physical Interface Module (Mini-PIM) Expansion Slots0200000
Physical Interface Module (PIM) Expansion Slots0043542
Enhanced PIM (EPIM) Expansion Slots0000024
802.11 a/b/gOptionalOptionalNoNoNoNoNo
Convertible to JUNOSNoNoNoYesYesYesYes
  • SSG5

    SSG5 Secure Services Gateway for small branch, teleworker, and enterprise deployments.

  • SSG20

    SSG20 Secure Services Gateway for small branch, teleworker, and enterprise deployments.

  • SSG140

    SSG140 Secure Services Gateway for midsize branch offices, regional offices, and enterprises.

  • SSG320M

    SSG320M Secure Services Gateway for midsize to large branch offices, regional offices, and enterprises.

  • SSG350M

    SSG350M Secure Services Gateway for midsize to large branch offices, regional offices, and enterprises.

  • SSG520M

    SSG520M Secure Services Gateway for large branch offices, regional offices, and enterprises.

  • SSG550

    SSG550 Secure Services Gateway for large branch offices, regional offices, and enterprises.

WAN connectivity + security

Combined high-performance WAN connectivity and security has the muscle to protect high-speed LANs against internal network, application-level, and content-based attacks.

  • Comprehensive unified threat management (UTM)

    Comprehensive UTM security features include stateful firewall, IPsec VPN, intrusion prevention system (IPS), antispam, Web filtering, and antivirus with antispyware, antiphishing, and anti-adware, capabilities.

  • Policy-Based Management

    Policy-based management allows centralized end-to-end life cycle management.

  • Integrated Firewall

    Firewall security integrated with routing in a variety of LAN/WAN interfaces reduces IT expenditures.
