ScreenOS version tested
ScreenOS 6.3
ScreenOS 6.3
Firewall Perf (Large Packets)
450+ Mbps
450+ Mbps
Firewall Performance (IMIX)
400 Mbps
400 Mbps
Firewall Packets Per Second
175,000 PPS
175,000 PPS
3DES+SHA-1 VPN Perf
175 Mbps
175 Mbps
Concurrent VPN Tunnels
500
500
Max Concurrent Sessions
64,000
64,000
New Sessions/Second
8,000
8,000
Max Security Policies
2,000
2,000
Max Security Zones
40
40
Max Virtual Routers
5
5
Max Virtual LANs
125
125
Fixed I/O
4x10/100/1000
4x10/100/1000
Mini-Physical Interface Module (Mini-PIM) Expansion Slots
0
0
Physical Interface Module (PIM) Expansion Slots
3
3
Enhanced PIM (EPIM) Expansion Slots
0
0
802.11 a/b/g
No
No
Convertible to JUNOS
Yes
Yes
ISDN BRI S/T PIM
Download
[
355 KB ]
355 KB ]
Ethernet Universal Physical Interface Modules
Download
[ 761 KB ]
761 KB ]
Physical Interface Module (PIM) Compatibility Matrix for J Series Routers and SSG Series Secure Services Gateways
Download
[ 232 KB ]
232 KB ]
Dual-Port T1/E1 Physical Interface Module
Download
[ 381 KB ]
381 KB ]
Dual-Port Synchronous Serial Physical Interface Module
Download
[ 392 KB ]
392 KB ]
G.SHDSL Physical Interface Module
Download
[ 417 KB ]
417 KB ]
Configuring the CX111 for the SSG Series
Download
[ 565 KB ]
565 KB ]
|
| Model Number | Description |
|---|---|
| SSG320M | |
| SSG-320M-SB | SSG320M, ScreenOS, Base Memory (256 MB), HW Security, AC Power Supply |
| SSG-320M-SH | SSG320M, ScreenOS, High Memory (1 GB), HW Security, AC Power Supply |
| SSG320M I/O Options | |
| JX-2T1-RJ48-S | 2-Port T1 PIM with integrated CSU/DSU |
| JX-2E1-RJ48-S | 2 Port E1 PIM with integrated CSU/DSU |
| JX-2Serial-S | 2-Port Synchronous Serial PIM |
| JX-1ADSL-A-S | 1-Port ADSL 2/2+ Annex A PIM |
| JX-1ADSL-B-S | 1-Port ADSL 2/2+ Annex B PIM |
| JX-2SHDSL-S | 2-Port 2-wire or 1-Port 4-wire G.SHDSL PIM |
| JX-1BRI-ST-S | 1-Port ISDN BRI S/T PIM |
| JXU-6GE-SFP-S | 6-Port SFP Gigabit Ethernet Universal PIM2 |
| JXU-8GE-TX-S | 8-Port Gigabit Ethernet 10/100/1000 Copper Universal PIM2 |
| JXU-16GE-TX-S | 16-Port Gigabit Ethernet 10/100/1000 Copper Universal PIM2 |
| JX-SFP-1GE-LX | Small Form Factor Pluggable 1000Base-LX Gigabit Ethernet Optical Transceiver Module |
| JX-SFP-1GE-SX | Small Form Factor Pluggable 1000Base-SX Gigabit Ethernet Optical Transceiver Module |
| Unified Threat Management/Content Security (High Memory Option Required) | |
| NS-K-AVS-SSG320 | Antivirus (includes anti-spyware, anti-phishing) |
| NS-DI-SSG320 | IPS (Deep Inspection) |
| NS-WF-SSG320 | Web filtering |
| NS-SPAM-SSG320 | Anti-spam |
| NS-RBO-CS-SSG320 | Remote Office Bundle (Includes AV, DI, WF) |
| NS-SMB-CS-SSG320 | Main Office Bundle (Includes AV, DI, WF, AS) |
| SSG320M Series Memory Upgrades, Spares and Communications Cables | |
| CBL-JX-PWR-AU | Power cable, Australia |
| CBL-JX-PWR-CH | Power Cable, China |
| CBL-JX-PWR-EU | Power Cable, Europe |
| CBL-JX-PWR-IT | Power Cable, Italy |
| CBL-JX-PWR-JP | Power Cable, Japan |
| CBL-JX-PWR-UK | Power Cable, UK |
| CBL-JX-PWR-US | Power Cable, US |
| SSG-300-MEM-1GB | 1 Gigabyte Memory Upgrade for the SSG300 Line |
| SSG-350-FLTR | Replacement air filter for SSG300 Line |
| JX-CBL-EIA530-DTE | EIA530 cable (DTE) |
| JX-CBL-RS232-DTE | RS232 cable (DTE) |
| JX-CBL-RS449-DTE | RS449 cable (DTE) |
| JX-CBL-V35-DTE | V.35 cable (DTE) |
| JX-CBL-X21-DTE | X.21 cable (DTE) |
| JX-Blank-FP-S | Blank I/O plate |
