CTP1002
CTP1002는 1 RU 랙 마운트형 섀시에서 2개의 회선 에뮬레이션 트래픽 인터페이스를 지원합니다.
Dimensions
- W x H x D: 8 x 1.75 x 12.5 in (20.3 x 4.5 x 31.8 cm)
- Weight: 6 lb
- Input Voltage (AC): 100-120VAC
- Input Voltage (DC): n/a
- Power Supply: 60 Watts
- Input Current: n/a
- Operating Temp: 0 - 40 C
- Humidity (Non Condensing): 5 - 90%
Serial Interfaces
- RS-232, EIA530, V.35, DS-1, E1: Yes
- IRIG-B: n/a
Data:
Encoding:
- NRZ, Conditioned Diphase, Isochronous, Asynchronous, AMI or B8ZS (T1): Yes
- NRZ, Conditioned Diphase, Isochronous, Asynchronous, AMI, B8ZS, HDB3, Milstar, Transparent: n/a
- Interface Quantity: 2
- Rates: 50 bps - 2.048 Mbps
- Analog Voice 4 -Wire TO Interface Quantity: n/a
IP Interfaces
- 100 Base T (RJ-45): 1
- 100 / 1000 Base T (RJ-45): n/a
- 100 Base FX (SC): n/a
- 1000 Base FX (SC): n/a
- SFP 1000Base-T: n/a
- SFP 1000Base-SX: n/a
- SFP 1000Base-LX: n/a
- Precedent Setting: Configurable TOS Byte (DSCP): Yes
677 KB ]
| Part Number | Description |
|---|---|
| CTP1000 Units | |
| CTP1002-P | CTP1002 chassis providing 2 EIA530/RS-422/X.21/V.11, RS-232/V.24, V.35 ports |
| CTP1002-4WTO | CTP1002 chassis providing 2 EIA530, RS-232, V.35, 4WTO ports |
| CTP1002-T1E1 | CTP1002 chassis providing 2 EIA530, RS-232, V.35, T1, E1 ports |
| CTP Software | |
| CTP-OS-1K | CTP1000 line - current software |
| CTPView | CTPView |
| CTP-DOC | Additional CTP Series manual current version |
